Package Contents

!
USRobotics Wireless ADSL2+ Router
!
9V DC Power supply
!
Ethernet cable

Physical Features

Front
The router has the following status
LEDs:
Symbol Name
Power
WLAN
(Wireless
Network)
WAN
(Internet)
ADSL
LAN
State Condition
Off Not receiving power.
Solid Receiving power.
Off Wireless connection is disabled.
Solid Wireless connection is enabled.
Flashing Sending and receiving data.
Off No Internet connection established or the router is in bridge mode.
Solid Internet connection is established.
Flashing Sending and receiving data.
Off No ADSL connection.
Solid ADSL link is achieved.
Flashing ADSL link is being established.
Off No LAN connection.
Solid LAN link is achieved.
Flashing Sending and receiving data.
!
Telephone cable
!
Installation CD-ROM
!
Quick Installation Guide
