Connecting the drain hose
! We advise against the use of hose extensions;
if it is absolutely necessary, the extension must
have the same diameter as the original hose and
must not exceed 150 cm in length.

Electrical connections

Before plugging the appliance into the electricity
socket, make sure that:
• the socket is earthed and complies with all
applicable laws;
• the socket is able to withstand the maximum
power load of the appliance as indicated in the
Technical data table (see opposite);
• the power supply voltage falls within the values
indicated in the Technical data table (see opposite);
• the socket is compatible with the plug of the
washing machine. If this is not the case, repla-
ce the socket or the plug.
! The washing machine must not be installed
outdoors, even in covered areas. It is extremely
dangerous to leave the appliance exposed to
rain, storms and other weather conditions.
! When the washing machine has been installed,
the electricity socket must be within easy reach.
Connect the drain
hose, without bending
it, to a drainage duct or
a wall drain located at a
height between 65 and
100 cm from the floor;
alternatively, rest it on
the side of a washba-
sin or bathtub, faste-
ning the duct supplied
to the tap (see figure).
The free end of the
hose should not be
underwater.
! Do not use extension cords or multiple sockets.
! The cable should not be bent or compressed.
! The power supply cable must only be replaced
by authorised technicians.
Warning! The company shall not be held responsible
in the event that these regulations are not respected.

The first wash cycle

Once the appliance has been installed, and before
you use it for the first time, run a wash cycle with
detergent and no laundry, using the wash cycle 2.

Technical data

Model IWDC 6145
width 59.5 cm
Dimen-
height 85 cm
sions
depth 53,5 cm
from 1 to 6 kg for the wash
programme;
Capacity
from 1 to 5 kg for the drying
programme
Electrical
please refer to the technical
c o n n e c -
data plate fixed to the machine
tions
maximum pressure 1 MPa
Water (10 bar)
connec- minimum pressure 0.05 MPa
tions (0.5 bar)
drum capacity 52 litres
Spin up to 1400 rotations per
minute
speed
Wash: programme 2; tempe-
Energy rature 60°C;
rated pro- run with a load of 6 kg.
grammes Drying: first drying cycle per-
according formed with a 1 kg load, by se-
to regula- lecting a drying time of 60 min;
Second drying cycle perfor-
tion
EN 50229 med with a 5 kg load and the
DRYING knob on the
This appliance conforms to
the following EC Directives:
- 89/336/EEC dated 03/05/89
(Electromagnetic Compatibility)
and subsequent modifications
- 2012/19/EU
- 2006/95/EC Low Voltage)
GB
setting.
3
