Overview of Functions

Button
Speed (17)
Swing (16)
Cold Warm (15)
Timer (14)
* The information in this column refers to the display above the corresponding button.
• By pressing a button several times, the respective function can be switched on and
off, or the user can switch between the various setting options of the function. This
results in the following options or sequences for the functions:
– Speed:
– Swing:
– Cold Warm:
– Timer:
• Depending on operating mode, the levels which can be set with the Speed button
refer to either the intensity or the speed:
Level
1
2
3
4
• As an alternative to the buttons on the control panel (5), the device can be controlled
using the buttons of the same name on the remote control.
PLEASE NOTE: Only the speed can be controlled with the Speed button on the
remote control, which means that the sequence is changed as follows: Level 1 (On) –
Level 2 – Level 3 – Level 4. Press the Standby button on the remote control to put
the device into standby.
Pressing the Standby button puts the device into standby without fi rst going
through the various phases.
23
Function
Switching On / Off
Setting the Speed / Intensity
(4 levels)
Switching Rotation On / Off
Setting the mode
(Cooling / Heating)
Setting the timer
(2H, 4H, 6H, 8H)
Level 1 (On) – Level 2 – Level 3 – Level 4 – Standby
On – Off
Cold – Warm
2H – 4H – 6H – 8H – Off
Heating mode
8 seconds of heating,
8 seconds pause
8 seconds of heating,
6 seconds pause
8 seconds of heating,
4 seconds pause
continuous heating
Display*
On: 1st bar lights up
Stand-by: 1st bar fl ashes
Level 1: 1st bar lights up
Level 2: 2nd bar lights up
Level 3: 3rd bar lights up
Level 4: 4th bar lights up
On: bar lights up
Off: bar is not lit up
Cooling: blue bar lights up
Heating: red bar lights up
depending on the setting, the
number lights up
Cooling mode
low speed
lower medium speed
upper medium speed
high speed
EN
