Technical Data

Operational voltage
Direct voltage 10.8 – 16 V
Ambient temperature
-20 °C up to +35 °C
Front plate Aluminum
Width 88 mm
Height 93 mm
Depth 20 mm
Weight 70 g
The right to effect technical modifications is reserved!

Maintenance

Clean the panel with a dry and fluff-free cloth.
Disposal
The device must be disposed of in line with the administrative
regulations of the respective country in which it is used.
National regulations and laws (in Germany, for example, the
End-of-life Vehicle Regulation) must be observed.

Troubleshooting

Error Rectification
The filling level display –
is not shown for the –
waste water tank.
The filling level display –
is not shown for the –
freshwater tank.
The voltage display is –
not shown. –
The charging control –
display is not shown.
The main switch does –
not react.
If these measures do not solve the problem, please
contact the Truma Service Centre.
Press the master switch.
Check the connection and the
cable to the waste water tank
and the connection and cable to
the MES Module B.
Press the master switch.
Check the connection and the
cable to the freshwater tank and
the connection and cable to the
MES Module B.
Press the master switch.
Check the connection and the
cable to the MES Module B.
Check the connection and the
cable of the MES Module B.
Check the connection and the
cable to the MES Module B and
the fuses and connections of the
MES Module A and B. See the
operating instructions for the
MES Module B.
