2. SETUP
• Connect the Outputs (RCA) -29- to the line input of your mixing console or connect the XLR Output -28- to your PA.
• Connect the mains cable -26- to your power outlet.
• Connect any rec source to the RCA Input -30- to be able to record the signal.
3. OPERATION
3.1 Basic Steps
Power On
After having finished all connections turn on the device via the ON/OFF Button -1-. The LED will be lit.
Loading a medium
• CD
Press the Open/Close Button -4- or -31- on the supplied remote control in order to open the CD tray -2-. Insert the CD. Press the Open/Close
Button once again in order to close the CD tray.
ATTENTION!
Never try to close the CD tray manually as this could damage the mechanism.
• USB
Connect a standard external USB device, such as an USB stick or USB hard disk with power supply of its own, to one of the USB ports -3- or -27-.
Please make sure that the used data carrier and its stored media files are supported. Further information regarding this issue can be found at
the end of this instruction manual.
3.2 Media Select (CD/USB)
If a compatible CD has been inserted or a suitable USB device is connected to one of the USB ports -3- or -27- it is possible to select the source by
pressing the Media Select Button -5- repeatedly. Alternatively it is also possible to select the device by using the Media Select Buttons -46- on the
remote control. The active device is displayed via the 3 LEDs next to the corresponding Select Button -5- on the front panel.
3.3 Track Select, Fast Forward and Rewind
Via the Track Select Encoder -16- it is possible to select tracks. By turning the Track Select Encoder clockwise the following tracks can be selected.
By turning the Encoder counterclockwise it is possible to return to previous tracks. By pressing and holding while also turning the Encoder 9 tracks
at once will be skipped. Alternatively it is also possible to use the Track Select Buttons -33- on the remote control. By pressing the Search Buttons
-20- or -32- you can fastforward (right button) or rewind (left button) a track.
If you would like to play an MP3 CD or a USB device that comprises various folders it is possible to navigate as follows: By briefly pressing the
Folder Button -18- the Track Select Encoder -16- will be put in browse mode. The folder LED is lit. By turning the encoder you can now navigate
through the folder structure. By pressing the Folder Button -18- again the Encoder will be put in track select mode once again. Alternatively it is
possible to select the folder via the Folder Buttons -34- on the remote control.
By briefly pressing the Track Select Encoder -16- while playing an MP3 title it is possible to show certain information on the display. Depending on
how the MP3's Tag has been organized, it is possible to select the following values:
• File Name:
Actual file name with file extension
• Title:
The title's name is displayed
• Artist:
The artist's name is displayed.
• Album:
The album's assigned name is displayed.
• Genre:
The genre that has been assigned to the track is displayed.
In the default settings the MP3's bitrate is additionally displayed. If you prefer to deactivate this additional information you can do so in the device
settings. Please see the chapter "Device Settings" for further explanations.
3.4 Playback
Press the Play/Pause Button -15- or -43- in order to start playback. By pressing the button again pause mode will be entered. The current medium
can be set into two different playback modes via the Single/Continue Button -9- or -39-.
a) Single
"Single" appears on the display. The current track is played, afterwards the player enters pause mode. If the repeat function (see next paragraph)
has been activated additionally, the current track will be repeated in an endless loop until this mode is turned off.
b) Continue
"Single" will disappear from the display. The whole CD or complete USB device is played. When reaching the end of a CD or a USB device's folder,
playback will restart from the beginning if the repeat function is active (see next paragraph).
Apart from these two modes it is also possible to activate the repeat mode. This can be de/activated by pressing the Folder Button -18- for a longer
period. The current status can be read via the "REPEAT" symbol on the display -N-. The effects of the repeat mode depend on active "Single" or
"Continue" mode. For further information please read the items "Single" and "Continue" in this chapter.
3.5 Jog Wheel Mode
Depending on the playback mode, the Jog Wheel -7- disposes of two different modes:
a) If the selected track is in pause or cue mode it is possible to search by frame (1/75 sec) via the Jog Wheel. In order to set a new cue point, for
example, turn the Jog Wheel until you reach the desired point and press the Play -15/43- or Loop-In Button -13/40-.
b) During playback of a track it is possible to temporarily increase (clockwise) or decrease (counterclockwise) a track's pitch. The longer the Jog
Wheel is turned in any of the two directions, the more the track's pitch will increase/decrease. Let go the Jog Wheel in order to exit pitch bend mode.
