INSTALLATION INSTRUCTIONS

ATTENTION: the device must only be installed by qualified personnel,
observing the current regulations and guidelines for KNX installations.
To correctly measure the controlled
ambient temperature,
thermostat must not be installed in
niches, near doors or windows, or
next to radiators or air-conditioning
units, and it must not be in the line
of draughts or direct sunlight.
The thermostat can be assembled on the rectangular flush-mounting box 3 (e.g:
GW24403) or on the square/round box (e.g: GW24231, GW24232) thanks to the included
metal fastening supports.

Correct positioning

the

Assembly
