4.3

Flat screen mounting

Tab. 16:
Allen key 4mm
with screwdriver
Phillips screwdriver
A
Fig. 20: Flat screen mounting 1
Fig. 21: Flat screen mounting 2
Risk of injury by tripping and falling
>>
ries in a safe way.
Risk of material damage by improper
procedure
>> Only use moderate force when tightening the screws
in order to avoid damaging threads.
>>
>>
2.
3.
protect it of scratches and overturn-
ing.
Dismantle the VESA plates off the
holder unit (A) by removing the
locking screws on the back side with
Allen key (P-A).
Attach the VESA plates with
screens by screws (M-A) or (M-B)
and washers (M-C).
-
P-A
23
