Tab. 15: Wall mounting
Allen key 4mm
with screwdriver
Allen key 5mm

4.2.1 Pre-assembly

Fig. 14: Desk Mounting - pre-assembly 1
Fig. 15: Desk Mounting - pre-assembly 3

4.2.2 Table edge mounting

Fig. 16: Desk mounting - Table edge mounting
Risk of material damage by inappropriate ambi-
ent conditions
>> Keep enough space around product and to the whole
system to ensure proper ventilation and mobility.
>>
>> Protect against pressure points.
1.
2.
3.
6.
Check the strength and stability of the
surface before installing and do not
damage them.
Choose a suitable mounting place.
Screw the rod unit (B) clockwise into
the desk clamp (C).
shown.
surface.
Clip the cover caps (D) on the right
and left side of the holder unit (A).
Thighten the desk clamp (C) clockwi-
se by hand.
P-A
P-B
