Divus CIRCLE small Kurzanleitung Seite 6

Quick Start Guide
MOUNTING GUIDE
1
Place the metal gasket on the mounting box - make
sure it's horizontal.
3
Connect 48 VDC DC IN power supply or POE+ to the
corresponding socket.
6
2
Fix the gasket to the mounting box with the provided
screws (2 screws in total).
4
OPTIONAL: connect RS-485 to the corresponding
socket (only required if I/O MODULE present).
