TDK-Lambda DRF960-xx-1 Handbuch Seite 19

Doc No. 260301
12. Connections – signal connector
Signal Connector Information
Signal connector used
Part Description
Pin Header S8B-PHDSS(LF)(SN)
Matching Housings, Pin & Tool
Part Description
Socket Housing
Terminal Pins
Hand Crimping YRS-620(SPHD-002T-P0.5)
YC-610R(SPHD-001T-P0.5)
Tool
Signal Connector Pin Assign
S8B-PHDSS(LF)(SN) (JST)
2 1
4 3
5
6
8 7
13. DRF960 series UL508 Listed Condition
WIRING
CONNECTOR Recommended Wire
INPUT
10~24 AWG
(L, N, )
OUTPUT
6~20 AWG
(+V, -V)
Part Name Manufact.
JST
Part Name Manufact.
PHDR-08VS
SPHD-002T-P0.5
SPHD-001T-P0.5
1. CB
2. CB_COM
3. NC
4. NC
5. CNT+
6. CNT-
7. PV
8. COM
Max. Torque
10.3 kgf.cm
(9 lbf.in)
23 kgf.cm
(20 lbf.in)
OUTPUT
(DC OK)
JST
JST
JST
TDK-Lambda
DRF960 Series
INSTRUCTION MANUAL
10.3 kgf.cm
10~24 AWG
(9 lbf.in)
