NOTE
Take care when using blower function. Ashes and other residue are blown away in an uncontrollable
way!

3. USAGE:

Vacuum cool ash and dry residue only
• Always make sure the filter is installed!
• When the container is full or it feels difficult to vacuum more dust, the filter needs to be taken out
and cleaned.
• While vacuum the fireplace ash, the ash temperature must be below 40°C. Do not vacuum the ashes
that fire is not extinguished! (Fig. 5)
G
TIP:
When suction power is reduced: carefully tap on the lid or carefully tap container to the floor to possi-
bly remove the blockade.

4. AFTER USAGE:

• Press the switch 12 to turn off vacuum cleaner.
• Pull out plug.
• Roll up the power cable.
• Disassemble the hose 7 from the appliance.
• Take the lid 3 from the appliance.
• Empty the container body 1 and wash it.
• Use rag to dry container body 1.
• Take out the filter B / C and (if applicable) the metal mesh cover D, and clean and wash it carefully
(picture 6), and dry it in air before installed on vacuum cleaner. Filter and metal mesh cover can be
removed using the 'turn anti clock wise and pull method'. For the metal mesh cover is might be nec-
essary to loosen the metal screws just a little bit.
• Reinstall B / C and D (if applicable) following the 'push and turn clock wise method'. Make sure that
the metal mesh filter is fixated by fixating the relative screws.
• Replace the lid 3 and fixate the locks 2

5. MAINTENANCE

The container body 1 and outer shell of lid 3 need to be cleaned frequently.
• Never use a detergent and/or cleaning agent as this might result in damages
• The dirty container should wash with the clear water only.
ASZ TYPE ONLY:
Make sure that water never comes in contact with the lid, as this can cause significant damage and or
risk with respect to the electrical parts!
• Wash the filter with the clear water only.
• If the appliance working unsatisfactory, it is usually resulted from the jam of hose 7 or conjunction of
pipes, filters or accessories. In that case, please clean the parts concerned.

6. CONSUMABLES AND SPARE PARTS:

• New filters can be obtained through your dealer. Check www.qlima.com for more information.
• Only use spare parts and/or consumables supplied by the manufacturer or its authorised service agent

7. TROUBLESHOOTING:

Review these tips first and you may not need to call for service.
24
DEVICE WILL NOT START
POSSIBLE CAUSE WHAT TO DO
Cord is not plugged into an electrical Make sure plug is fully inserted into the wall outlet.
outlet. Replace fuse or reset circuit breaker.
A fuse may be blown or the circuit may Switch on.
be breaker tripped.
Not switched on.
VACUUMING NOT AS STRONG AS NORMAL
POSSIBLE CAUSE WHAT TO DO
Full ash bucket Empty ash bucket
Full filter Clean the filter (see relevant paragraph)
Exchange the filter (filter is a consumable)
TECHNICAL DATA AND PRODUCT FICHE
QLIMA ASE1020 QLIMA ASZ1010
Power input (Watt) n/a
Power supply 220-240 V~ / 50 Hz / 1 Ph
IP Rating n/a
Sound pressure (dB(A)) (*) n/a
Tank volume (liter) 20
Weight (kg) 2.8
Vacuum (kPa) n/a
(*) for reference only

8. STORAGE INSTRUCTIONS

If children play with the appliance, make sure that dangerous parts are removed. Never dispose of
non-biodegradable products in the environment, but dispose of them in accordance with current na-
tional legislation.

9. GUARANTEE CONDITIONS

The appliance is supplied with a 24-month guarantee, commencing on the date of purchase. All mate-
rial and manufacturing defects will be repaired or replaced free of charge within this period. The fol-
lowing rules apply:
1. We expressly refuse all further damage claims, including claims for collateral and/or consequential
damage.
2. Repairs to or replacement of components within the guarantee period will not result in an extension
of the guarantee.
3. The guarantee is invalidated if any modifications have been made, non-genuine parts are fitted or
repairs are carried out by third parties.
4. Components subject to normal wear, such as filters, batteries, lamps and heating elements are not
covered by the guarantee.
5. The guarantee is valid only when you present the original, dated purchase invoice and if no modifi-
cations have been made to it.
6. The guarantee is invalid for damage caused by neglect and/or by actions that deviate from those in
this instruction booklet.
7. Transportation costs and the risks involved during the transportation of the appliance or compo-
nents of the appliance shall always be for the account of the purchaser
8. Damage caused by not using suitable spare parts is not covered by the guarantee.
To prevent unnecessary expense, we recommend that you always first carefully consult the instructions
for use. Take the appliance to your dealer for repairs if these instructions do not provide a solution.
www.qlima.com
QLIMA ASZ 1020
600 1200
IPx0
76 80
12 20
2.8 3.6
≥14 ≥19
25
