DUPLO PRO
Choosing where to install the safety seat
Correctly choosing where to position the safety
seat in the car can reduce the risk of injury to the
baby in the event of an accident.
Reclining position, Group 0. The safety seat must
be installed cross-wise in the back seats. DUPLO
PRO occupies two seats: you can choose between
a side and a middle seat, so an adult can travel
alongside, or completely in the middle. If you
decide on middle and side seats, place the DUPLO
PRO so that the head is as far as possible from the
door.
Seated position, Group 0+. Whenever possible,
install the safety seat in the back seats. It is highly
advisable that someone travels alongside the baby
to take care of them. Of the three back seats, the
middle one is the safest.
20
IM1268_DUPLO PRO.indd 20
If you are travelling alone with your baby, it is a
good idea to keep them in sight without being
distracted while driving. You can position them in
the passenger seat, providing it does NOT have an
airbag or the airbag IS DISCONNECTED. Do not
be distracted for any reason while driving: to take
care of the baby, stop the car completely in a safe
place.
3 Installing the seat in the car
Reclining position, GROUP 0
In the reclining position, DUPLO PRO must be
fitted cross-wise on the back seats. Decide on
which seats after reading the section on
"Choosing where to install the safety seat".
3a - Fasten the two belts that you have chosen. The
anchorages should be installed in the abdominal
part of the belt: this zone is shown in light blue in
the diagrams.
3b - Open the anchorages.
3c - Pass the flap of each anchorage underneath
the abdominal part of the belt. The eyelet of the
anchorage should point outwards (opposite side to
the car buckle).
3d - Close the anchorage.
3e - Place the DUPLO PRO on the seat. Turn the
anchorages to the vertical position and fit them on
the pivots of the safety seat.
3f - Finally, tighten both belts.
