Operating instructions
Fitting and changing accessories
1. Flip up the catch on the tool
bracket fully.
3. Close the catch fully.
Fitting the dust extractor connection
1. Place the dust extractor
connection over the accessory
bracket. Make sure that
the locking knob is located over
the threaded hole in the multi-tool.
2. Tighten the locking knob.
2. Place the accessory required in the bracket
and make sure that the tool sits correctly on
the bracket's retaining pins.
