LD Systems PLAY SERIE Bedienungsanleitung Seite 6

FEATURES:
1
GRAPHIC EQUALIZER
5-band graphic equalizer
2
MP3 LEVEL
Volume control for digital audio
player
3
MICROPHONE INPUT
Balanced XLR input / unbalanced
jack input for microphones
4
MICROPHONE LEVEL
Volume control for microphone
input
5
LINE INPUTS
Balanced XLR input / unbalanced
cinch line input
6 LINE IN LEVEL
Volume control for line input.
7
MASTER VOLUME
Mastervolume control
8 LINE OUTPUTS
Balanced XLR and jack mono
outputs. The mixed input signals
are split before the power amplifier
unit and sent to this output. You
can use this output, for example,
to drive additional active speakers
or amplifiers with the mixed input
signals.
Important: This output signal is
determined before the master
tone controls and the master
volume, so it is independent of
other settings.
6
PLAY PREV NEXT-
INPUT
REPEAT EQ
PAUSE VOL- VOL+
USB
MP3
SD
SD/MMC
USB
Digital Audio Player
3
5
8
12
1
2
4
6
7
9
10
14
11
13
