TDK-Lambda DPP15 Handbuch Seite 17

Product HANDBOOK
Outline drawing DPP100 Series
Pin number
1
2
3
4 Neutral AC Input
5
6
7
Potentiometer
Green Led (Lit)
TDK-Lambda UK Ltd
Kingsley Avenue, Ilfracombe
Devon, EX34 8ES
Telephone - Sales and Service +44 (0)1271 856666
Head Office and Works +44 (0)1271 856600
Facsimile +44 (0)1271 864894
WEBSITE: www.uk.tdk-lambda.com
Page 17 of 17
DPP15 to 100-xx-1
DPP15
-DC Output
+DC Output
Earth Input
Live AC input
Not present Neutral AC Input
Not present
Vout Adjust
DC ON
DPP25 - 50
-DC Output
-DC Output
+DC Output
+DC Output
Earth Input
Neutral AC Input
Live AC input
Vout Adjust
DC ON
DPP15 to 100-xx, 23414 issue 02, April 2013
DPP100
-DC Output
-DC Output
+DC Output
+DC Output
Earth Input
Live AC input
Vout Adjust
DC ON
