4. Overview
Refer to the illustrations on page 2 of this manual.
1 status LED
2 SD/SDXC/MMC slot
3 ATM/EID slot
5. Use
• Before connecting the PCUSB38 to a PC insert the included CDROM in the
CDROM player. The software installer program will open automatically. If
not, locate autorun.exe on the CD and double click it.
Note: make sure the PC is running a compatible operating system (refer to
§6).
• Click on SIM/SMART driver and follow the instructions on the screen.
• Plug the USB connector [6] into the USB port of the PC.
• Insert your memory card in the appropriate slot [2, 5] and open the
designated drive to view/change the content.
• Insert a SIM card into the SIM slot [4] to organize your phonebooks etc. on
your SIM card. Locate the SIMedit icon and double click it to start the
software. Refer to the full user manual on the CDROM for more details.
• To read an ATM or EID card, install the necessary software before placing
the card in the ATM/EID slot [3].
Note: when using the EID card reader, additional software may be required
depending on the country of origin of the ID card:
For Belgium, see
For Spain, see

6. Technical Specification

compatible with
transfer rate
available slots
dimensions
weight
Use this device with original accessories only. Velleman nv cannot be held
responsible in the event of damage or injury resulted from (incorrect) use of
this device. For more info concerning this product and the latest version of
14.11.2012
http://eid.belgium.be/
http://www.dnielectronico.es/descargas/index.html
Windows® 7, Vista 32/64, XP SP2, 2000 SP4, Mac
10.5.0
USB1.1 up to 12Mbps
USB2.0 up to 480Mbps
SIM, Micro SD, SD/SDXC/MMC, smart card
70 x 36.5 x 13.5mm
±22g
PCUSB38
4 SIM slot
5 Micro SD card slot
6 USB connector
