PCUSB10 – USB 2.0 HUB (3 PORTS) + MULTICARD READER/WRITER, 21 CARD TYPES, HIGH SPEED
1. Introduction & Features
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the PCUSB10! Please read the manual thoroughly before bringing this device into service. If the
device was damaged in transit, don't install or use it and contact your dealer.
The PCUSB10 contains: USB 2.0 Card Reader/Writer with 3-port HUB, USB connection cable (4 x 5 pins), CD driver,
this manual.
Its features are:
• 21-in-1 card reader/writer with built-in USB 2.0 HUB, 3 ports
• USB 2.0 transfer rate up to 480Mb/sec, backward USB 1.1 compatible (max. 12Mb/sec)
• USB powered or external mini 220VAC / 5VDC power adapter (not included)
• 5 LED indicators for power ON, card reader access, USB port 1, 2, 3 connected
• Data copying between cards without intermediate storage
• Compact & lightweight design
• Display for name or logo with EL backlight
• All-in-1 design, the 4 memory card slots support 21 digital memory card types (see below)
Slot 1: CF type I, CF type II, CF-Ultra II, Micro Drive
Slot 2: MS, MS (Magic Gate), MS-Pro (Magic Gate), HS-MS-Pro-Duo (Magic Gate)
**MS-Duo (Magic Gate), MS-Pro-Duo (Magic Gate), HS-MS-Pro-Duo (Magic Gate)
Slot 3: SD, SD-Ultra, SDC, MMC, HS-MMC, RS-MMC
**Mini SD, T-Flash
Slot 4: SM, X Card
(** indicates that a card adapter is required)
2. Specifications
• Supports Windows ME/2000/XP & Mac OS X without device driver
• Supports Windows 98SE with USB device driver (incl.)
• Power: USB bus powered or 5VDC power supply (not incl.)
• Dimensions: 85 x 70 x 15.5mm
• Weight: 74g
• Comes with connection cable (100cm) & driver (on CD)
1. USB port
2. Port 1, 2, 3
3. Card reader access LED
4. Power ON LED
PCUSB10
USB + LIGHT
5. Slot 1
6. Slot 2
7. Slot 3
8. Slot 4
9. USB upstream
10. DC jack
1
VELLEMAN
