Calix M7T 933 Einbauhinweise

Part no. 2201284
9
8
5
3
7
11
5
6
4
1 Anslutningssladd MS 8 Kupévägguttag
Liitäntäjohto / Connecting Sisätilapistorasia / Cab
cable / Anschlusskabel wall socket / Heizlüfter-
Steckdose
2 Intagskabel MK
9 Kupévärmare
Elementtikaapeli / Inlet
cable / Einbaukabel Sisätilanlämmitin / Cab
heater / Heizlüfter
3 Batteriladdare BL
10 App för Calix timer
Akkulaturi / Battery Charger
/ Batterielader Calix-timer applikaatio /
Application for Calix timer /
4 Bluetooth relä
App für Calix Timer
Bluetooth rele / Bluetooth
11 Strålningsskydd
relay / Bluetooth Relais
Lämpöeriste / Heat Shield /
5 Skarvkabel
Hitzeschutz
Jatkokaapeli / Extension
12 Pump
cable / Verlängerungskabel
Pumppu / Pump / Pumpe
6 Grenuttag
Haaroituspistorasia / Multi-
ple socket / Verteilerstück
7 Motorvärmare
Vastusosa / Engine heater /
Motorvor-wärmer
Low Voltage Directive, 73/23/EEC, the EMC
Directive, 89/336/EEC, including amendments
10
by the CE marking Directive, 93/68/EEC
Product
Engine preheater .................................................. MVP...
Inlet cable ................................................................. MK
Mains supply cable .....................................................MS
12
The following harmonised European standards or technical
specifications have been applied:
Standards
SS 433 07 90 .....................SEMKO ..........electrical safety
EN 60 335-1 ......................SEMKO ..........electrical safety
EN 60309-1/ 2 (1992) ........SEMKO ..........electrical safety
CENELEC HD 22 .................SEMKO ..........electrical safety
CEE 7 .................................SEMKO ..........electrical safety
EN 50 081-1 (1992) ............SEMKO ............EMC-emission
2
1
EN 50 082 (1995) ..............SEMKO ........... EMC-immunity
– The products comply with the LVD safety standards as per
above.
We have an internal production control system that ensures
compliance between the manufactured products and the
technical documentation.
– The products comply with the harmonised EMC standards
as per above.
The products is CE marked in -96.
As manufacturer, we declare under our sole responsibility
that the equipment follows the provisions of the Directives
stated above.
Calix AB
PO-Box 5026
SE-630 05 Eskilstuna
Sweden
medlem av
member of
mitglied von
Type designation
Test reports issued by Regarding
Eskilstuna, January, 2018
Henrik Gadd, President
Phone: E-mail:
+46 (0)16-10 80 00 info@calix.se
Support: E-mail:
+46 (0)16-10 80 90 teknik@calix.se
Fax: Internet:
+46 (0)16-10 80 60 www.calix.se
medlem av
member of
mitglied von
MONTERINGSANVISNING
ASENNUSOHJEET
ASSEMBLY INSTRUCTIONS
EINBAUHINWEISE
TYP M7T 933
EFFEKT: 750W / 230V ~
18.05.22.
IP46
