3.
Connect the monitor to the OmniView
included with your monitor, connect it to the HDDB15 female port on the back of the
OmniView ™
4.
Connect the keyboard and mouse to the OmniView
keyboard, you will need an AT-PS/2 adapter (Belkin Part# F2N017).
PS/2 Style Keyboard
5.
Connect the first computer's VGA cable to the OmniView
(Belkin Part# F2N025-XX-T or A3H981-XX), connect the male end of the cable to the
VGA port on the computer, and the female end on the PC1 VGA port at the back of
OmniView ™
Back of OmniView ™ PRO
4/21/00 2:25 PM
Hardware Installation
PRO labeled with the monitor symbol at the CONSOLE section.
PRO.
Page 7
(continued)
™ PRO. Using the attached cable, or the one
Back of OmniView
™ PRO. If you have an AT-style
PS/2 Mouse
™ PRO. Using the VGA cable
F2N025-XX-T
7
™ PRO
Back of OmniView ™ PRO
Back of PC
En
