Before Installation - Daikin EDEH04A6 Installationsanleitung

EDEH04A6
EDEHS06A6 EDEHB06A6
EDEHS10A6 EDEHB10A6
EDEHS12A6 EDEHB12A6
EDEHS18A6 EDEHB18A6
Read this manual attentively before starting up the unit. Do
not throw it away. Keep it in your files for future reference.
Improper installation or attachment of equipment or
accessories could result in electric chock, short-circuit,
leaks, fire or other damage to the equipment. Be sure only
to use accessories made by Daikin which are specifically
designed for the use with the equipment and have them
installed by a professional.
If unsure of installation procedures or use, always contact
your Daikin dealer for advice and information.
All field wiring and components must be installed by a
licensed electrician and must comply with relevant local
and national regulations.
B
EFORE INSTALLATION
Installation and maintenance should be carried out by technical
personnel qualified for this type of machine, in compliance with
current safety regulations.
When receiving the kit please check its state, verifying if any damage
occurred during transport.
Identify model and version of the electrical heater series from the
indications stated on the carton package.
The EDEH heating element must be combined with the
ECFWER6 controller + eventual EPIA6 or EPIMSA6.
C
HARACTERISTICS
Supplied to supplement conventional hot water heating (e.g. fan coil
units served by a heat pump) or users who wish to employ electric
heating. The optional EDEH (electric heater kit) elements can be
used on all FWD thermal ventilating units.
The EDEH option is available in following versions:
Electrical input
Electric
Unit heater (kW)
FWD04 EDEH04 2.0
EDEHS06 3.0
FWD06
EDEHB06 6.0
EDEHS10 4.5
FWD08
FWD10
EDEHB10 9.0
EDEHS12 4.5
FWD12
EDEHB12 9.0
EDEHS18 9.0
FWD16
FWD18
EDEHB18 12.0
Daikin will not be liable for any faults or damage caused by
improper use of the
consequences of selecting an inadequate controller.
EDEH04+EDEHS+B06~18A6
Electric heater kit
4PW17563-1A
Current rating Power supply
(A) (V) (f) (Hz)
8.7 230 1 50
4.3 400 3 50
8.7 400 3 50
6.5 400 3 50
13.0 400 3 50
6.5 400 3 50
13.0 400 3 50
13.0 400 3 50
17.3 400 3 50
EDEH module and/or for
Electric heater kit
The kit shown in figure 1 consists of:
■
Electric heater assembly made of:
A finned heating elements made of aluminium, complete with
supporting brackets for fastening them to the load bearing
structure of the electric module, which is built from thick
galvanised sheet metal, duly insulated and provided with an
electric control panel for housing the power relays and wire
terminals. In conformity with electric safety directives, the module
is equipped with automatic reset safety devices (one for each
heating element) and one manual-reset safety device.
B an automatic-reset safety thermostat mounted on the heating
element, which switches it off should overheating occur as a
result of irregular operating conditions or a fault in the fan motor
unit;
C a manual-reset safety thermostat, mounted on the load bearing
structure, which switches off the heating element in the event of a
simultaneous failure of all automatic-reset safety thermostats.
NOTE When the manual reset safety thermostat has tripped,
it can be reset as follows: (See figure 1)
1. unscrew the black cap inside the electric box
2. press the white button to reset the manual-reset safety
thermostat
3. re-install the black cap.
Sensor position of the manual reset safety thermostat
Even if the electric heater is not used in the standard
configuration, the sensor of the manual-reset safety
thermostat always needs to be positioned in the top part of
the electric heater. This means that for some applications,
the sensor will need to be re-positioned. See figure 2.
■
Standard (horizontal installation). (See figure 2-1)
Electric box of electric heater is at the same side of
the standard water connections of the unit. No need to
reposition the capillary bulb.
■
Non standard (horizontal installation)
Electric box of electric heater is at the opposite side of
the standard water connections of the unit.
Reposition the capillary bulb according to figure 2-2.
■
Non standard (vertical installation)
Reposition the capillary bulb on the top of the
automatic-reset
figure 2-3 and figure 2-4.
If more than 1 heating element, always select the top one
looking in the airflow direction.
If the capillary bulb needs to be repositioned, take care to
fasten it securely with the provided clamps using the holes
foreseen for this purpose.
D an electric box incorporating the power contactors, connection
terminals and manual-reset thermostat;
E L-shaped brackets and screws for fastening the module to the
unit outlet,
F sensor of the manual-reset safety thermostat.
Installation manual
safety thermostat according
Installation manual
