Trix IC 2206 Bedienungsanleitung Seite 7

CV Discription
1 Address
4 Braking delay
8 Reset
17 Extendet address (upper part) (CV 29, Bit 5=1)
18 Extendet address (lower part) (CV 29, Bit 5=1)
Bit 0: Travel direction polarity reversal
Bit 1: number of speed levels 14 – 28/126
29 Bit 2: DCC Operation with braking Block
DCC-, Selectrix and DC power operation
Bit 5: address size 7 Bit / 14 Bit
par Discription
001 Address for one and ten placeholder
002 Address for hundred and thousand placeholder
012 Braking delay
031 Travel direction polarity reversal
101 Reset
Factory
DCC Value
Setting
1 – 127 3
1 – 127 5
8 131
0 – 255 195
0 – 255 242
6
0 – 255
Factory
SX2 Value
Setting
0 – 99 1
0 – 99 10
0 – 99 5
0 / 1 0
101 131
7
