• Never let children play with the product.
• Store the device in a dry well-ventilated area.
• Avoid exposing the charger to direct sunlight.
• Check the mains lead and device regularly for defects. Allow only qualified
workshops or service staff to perform repairs or service on this product.

Product description

Fully automatic three-stage charger for motorcycles, snowmobiles, ATV's, etc. with
6 V or 12 V batteries. Charges batteries from 1.2 Ah to 20 Ah. Suitable for AGM and
Gel batteries. Built-in spark- and short-circuit-protection. LED indicators for charge
status and reverse polarity Output current: 0.2 A/0.75 A.

Buttons and functions

LED1
• Charging mode:
• Maintenance charging (pulse charging)
• Low battery*
• Reverse polarity
• No charging (clamps not connected)
*Low battery. This charger is not capable of charging a 12 V battery with a voltage
across its terminals that is under 7.5 V or a 6 V battery with a voltage across its
terminals as low as 3.75 V. Batteries with voltages this low are in all likelihood beyond
repair and should be replaced.
230 V.
Red lamp lit (LED 1)
Green lamp lit (LED 2)
Green lamp flashing (LED 1)
Red lamp lit (LED 2)
None of the lamps lit
4
LED2
6 V/12 V
