Dimensions:
millimeters (inches)
Model No.
CT15 37 (1-1/2")
CT60 62 (2-1/2")
CT150 62 (2-1/2")
CT300 62 (2-1/2")
CT400 62 (2-1/2")
CT600 62 (2-1/2")
CT600-**-F-*-*
CT750
CT800
CT1500 140 (5-1/2")
CT1500 includes 4 feet on base, add 20 mm (3/4") to D for full height. CT1500 is fitted with carry handles -
not shown on diagram. SR version is 9mm (3/8") shorter on the D dimensions
A
* CT15 has 1 x Pressure / Temp. & 1 x M10x1
6
A B
136 (5-3/8")
190 (7-1/2")
190 (7-1/2")
190 (7-1/2")
190 (7-1/2")
212 (8-3/8")
100 (4") 212 (8-3/8")
100 (4") 212 (8-3/8")
100 (4") 212 (8-3/8")
260 (10-1/4")
One M16 x 2 test point
fitted as standard
E
B
C D
37 (1-1/2") 123 (5")
50 (2") 136 (5-3/8")
50 (2") 136 (5-3/8")
50 (2") 140 (5-1/2")
50 (2") 140 (5-1/2")
75 (3") 156 (6")
75 (3") 160 (6-1/4")
75 (3") 160 (6-1/4")
75 (3") 160 (6-1/4")
100 (4") 176 (7")*
Pressure / Temp.
connections
M10 Port
E Weight kg (lbs)
69.5 (2-3/4") 0.7 (1.5)
103 (4") 1.6 (3.5)
103 (4") 1.6 (3.5)
103 (4") 1.7 (3.7)
103 (4") 1.7 (3.7)
127 (5") 2.7 (6)
126 (5") 5.0 (11)
126 (5") 5.0 (11)
126 (5") 5.0 (11)
130 (5-1/8") 10.0 (22)
D
C
