Channel
The channel of a hand-held transmitter can be programmed into one or more
receivers. One receiver is operated through an individual command, several
receivers through a group command.

Central command

If all the channels of the transmitter are selected, it is possible to operate all of
the assigned receivers/groups simultaneously.
Channel selection button
Up to 10 channels can be selected using the channel selection button. The in-
dividual channels are indicated by the corresponding LED lighting up.
Channel
1-5 and central command 1-5
6-10 and central command 6-10
1-10 central command
You can make a note of the programmed channel in the la-
belling field underneath the transparent film. If you keep the
channel selection button pressed for 3 seconds, the channel
selection sequence will change.
Channel indicator lamps
A radio signal is indicated by the corresponding channel indicator lamp light-
ing up. The respective channel indicator lamp flashes while transmitting if the
battery is getting weak. The transmission strength and the radio range de-
crease as battery power declines. If the channel indicator lamp no longer
lights up when a button is pressed, the battery must be replaced.

Explanation of functions

LED colour
green
red
orange
