4. REFERENCE PART

4.1. Error handling

Error description
Machine does not start
Display does not light up
Paper jam in the
machine
Paper jam in the stacker
Fold A is too short
Fold A is too long
Fold B is too short
Fold B is too long
Paper is not fed good
enough
The fold is to slope
Paper is not fed together
(only for the TF MULTI+) wrong
Error description on the display:
Error 1
Error 2
Error 3
Error 4
Possible reason
No current
Fuse blown out
Fold pockets are
blocked
Feeding is blocked
Stacker is not drawn Move the stacker to the correct
out far enough
Fold pocket 1 is
displaced
Fold pocket 1 is
displaced
Fold pocket 2 is
displaced
Fold pocket 2 is
displaced
Pressure spring
displaced
Paper try displaced
Feeding time is
Lever for the paper
jam removal is open
Overpowered
The folder was
overpowered
Paper jam in the
machine
No paper tray
selected (only for
the TF MULTI plus)
Corrective action
Check the power supply, the socket
and the cable
Check the fuse (see page 14, fuse
type 1,5 A slow)
Remove any possible paper in the fold
pockets (see drawing page 14)
Remove any possible paper at the
feeding unit (see point 2.4)
position according to the fold type (see
under 2.3)
Move the position index A for the fold
A downwards (see under 3.5)
Move the position index A for the fold
A upwards (see under 3.5)
Move the position index B for the fold
B upwards (see under 3.5)
Move the position index B for the fold
B downwards (see under 3.5)
Move the pressure spring at the rear
of the paper tray (see under 2.1)
Stronger pressure – Spring to +
Reduced pressure – Spring to -
Correct the paper try (see under 3.6)
Correct the feeding time for the
feeding stations (see under 3.8.2)
Close the lever (see under 2.1)
Switch off the folder, remove a possible
paper jam and switch on the machine.
Remove any possible paper in the
Machine and the fold pockets (see
drawing page 14)
Select the paper tray(s) needed (see
under 2.1)
15
