3. WORKING WITH THE MACHINE

3.5 How to correct the fold position

If you need to change the fold position this can be done very easily (scale +/-)
Move the position marker by using the vernier adjustment A or B.
1. Paper feeding
2. Select fold type
Wrap fold (Letter size documents 8 ½ x 11")
For the correct result of the wrap fold you need to adjust two fold positions.
The position marker A controls the length A.
The position marker B controls the length B.
To reduce length A
To increase length A
To reduce length B
To increase length B
Z-fold (Letter size documents 8 ½ x 11")
For the correct result of the Z-fold you need to adjust two fold positions.
The position index A controls the length A.
The position index B controls the length B.
To reduce length A
To increase length A
To reduce length B
To increase length B
= move the position marker A to -
= move the position marker A to +
= move the position marker B to -
= move the position marker B to +
= move the position marker A to -
= move the position marker A to +
= move the position marker B to -
= move the position marker B to +
11
