LED floodlight with motion detector
By purchasing this item, you have warranty cover damage resulting from
chosen a high-quality GEV product. failure to observe these instructions.
Please read these operating Nor do we accept liability for any indirect
instructions carefully to ensure damage.
correct operation. Keep these Similarly, we can accept no liability for
instructions in a safe place so that you any material damage or bodily injury
can refer back to them if necessary. caused by mishandling or failure to
observe the safety instructions. No
Operation warranty claim may be made in these
cases.
The LED floodlight with motion detector
In addition, for safety and compliance
functions using passive infrared
reasons, you are not authorised to
technology. If the motion detector's PIR
dismantle or alter the device in any way.
sensor detects a moving heat source
in its field of detection, it switches on
Mounting position
automatically. Static heat sources do
not activate the motion detector. The
Motion detection is maximised when
adjustable twilight switch can be set
moving at an angle to the motion
to ensure that the motion detector will
detector. Therefore, the motion detector
operate either during the day and night
should always be installed in a position
or only when it is dark. When movement
that ensures that objects/people do not
is detected, the motion detector
move directly towards the device.
switches on the LED and then switches
it off again between approx. 25 seconds
Installation
and approx. 5 minutes after the last
Install the light as shown in Figs. B to
movement is detected, depending on
E. Connect the mains connection cable
the setting.
as shown in the wiring diagram (Fig. D).
Safety instructions
Settings
This device must be installed by
TIME use to set the ON period to
a technician, in accordance with
between approximatey 25 sec. and
the applicable regulations. The
5 min. (Fig. F).
electrical power supply and the circuit
LUX adjust the twilight switch to
protection must be switched off during
between approximately 3 and 1,000 lux
the entire installation process. Please
(Fig. G).
check that the connection cable is
disconnected!
Under no circumstances does the
The motion detector can be adjusted
horizontally (Fig. H). You can also
restrict the angle of detection and the
range by attaching a lens mask, which
can be cut to size.
Adjust the floodlight to the required
position (Fig. I).
Recycling instructions
This device may not be disposed
of with unsorted household waste.
Owners of old devices are required
by law to dispose of this device
correctly. Contact your town council for
further information.
6
Technical data
Operating voltage 230 V ~, 50 Hz
Field of detection 140 °
Range approx. 8 m, depending on the installation height
Time setting approx. 25 seconds to 5 min, infinitely variable
Twilight switch approx. 3 - 1,000 lux, infinitely variable
LLL 14701 lamp power 1 x 4 W LED, maintenance-free
LLL 14718 lamp power 2 x 4 W LED, maintenance-free
LLL 14701 luminous flux 225 lumens
LLL 14718 luminous flux 450 lumens
Light colour 6300 K
Colour rendering index > 65
LED angle of radiation 30 °
Protection type IP44
Protection class II
Ambient temperature approx. -20 °C ...+40 °C
Recommended installation height 1.8 m
LLL 14701 dimensions approx. W 75 x H 140 x D 145 mm
LLL 14718 dimensions approx. W 124 x H 140 x D 117 mm
Technical and design features may be subject to change without notice.
