CONNECTION DIAGRAM

GB

BASIC SYSTEM

SEE PAGE PAG. 44
SHOWING THE MAIN
CONNECTION DIAGRAM
BLUE
HYIDRAULIC-
MAGNETIC
CIRCUIT
BREAKER
L2
L5
14
MULTI-PURPOSE
WATERTIGHT HAND HELD
REMOTE CONTROL
MOD. 1002
WINDLASS
BLUE
BATTERY
-
+
L3
L4 L1
M2
M1
C
"QUICK™" ACCESSORIES
FOR WINDLASS OPERATION
WATERTIGHT HAND HELD
CHAIN COUNTER
CHAIN COUNTER
REMOTE RADIO CONTROLS
RECEIVER
FOOT SWITCHES MOD. 900U AND 900D
BLACK
BROWN
BLUE
FUSE
REVERSING
SOLENOIDS UNITS
MOD. T503 (12V)
MOD. T504 (24V
)
A2
WATERTIGHT
PANEL
TRANSMITTERS
RADIO POCKET - HAND SET
A1
L = L1 + L2 + L3 + L4 + L5
WINDLASSES
CONTROL
BOARD
UP
DOWN
1 2
1 2
