3. Hardware Installation CHD3SIU
3.1 Assembling the CHD3SIU (When no hard disk is installed yet)
If you bought the CHD3SIU with a hard disk pre-installed, you can skip this step and
continue to step 3.2
a. Remove the 2 screws at the back of the CHD3SIU and remove the back plate.
b. Gently slide the hard disk tray out of the housing.
c. When installing an IDE hard disk, connect the power and IDE cable to the hard disk
and place the hard disk in the tray.
Note: You need to set your hard disk to 'Master' or 'Single', depending on the
type of hard disk you are using. How to make this setting, is indicated on
your hard disk itself or in its manual.
When installing a Serial ATA hard disk, remove the IDE cable from the board and
connect the Serial ATA cable. Connect the Power cable and Serial ATA cable to the
hard disk and place the hard disk in the tray.
Note: Most Serial ATA hard disks have 2 power connections: 1 general
connector, and 1 Serial ATA Power Connector. In case you want to use
the Serial ATA Power Connector, don't connect the general power
connector to the hard disk!
d. Turn over the tray and use the 4 supplied screws to fasten the hard disk to the
tray.
e. Slide back the tray in the housing, attach the back plate to the backside of the
tray and use the 2 screws to fasten the back plate.
