GB
MODELS
The TANGO SW and the BLEU ranges comprise:
Transmitters:
TANGO 2 SW :
TANGO 4 SW :
BLEU 2
BLEU 4
Receivers:
TANGO SR1 SW : 1-channel plug-in receiver for Telcoma control units
TANGO SR2 SW : 2-channel plug-in receiver for Telcoma control units
TANGO RB1 SW : Mini 1-channel receiver with terminal board
TANGO RB2 SW : Mini 2-channel receiver with terminal board
TANGO R4 SW :
BLEU
FEATURES
The receivers are self-learning and the receiver relay outputs are with
clean contact.
The code in the TANGO SW range transmitters must be set manually
through the 10-way dipswitch, which is to be found inside the actual
transmitter (Fig.4).
The BLEU range of transmitters need no programming, since the code
(different for each one) is set directly in the factory during the final test.
To customise the code, see section BLEU TRANSMITTER CODING.
34
2-channel transmitter
4-channel transmitter
Mini 2-channel transmitter
Mini 4-channel transmitter
Modular 4-channel receiver with terminal board
Use the TANGO SW range of receivers
