Actuating The Code Button - Becker Centronic EasyControl EC611 Montage- Und Betriebsanleitung

Actuating the code button

An opening code must first be entered in order to operate a receiver using the
code button. The factory setting for this is "1111". The user can change the
opening code individually to a different number combination.
1 1 1 1
5
7
9
22 - en
Briefly press the "Bell" button so that the code button is
ready for operation.
▻ The blue LED lights up.
Now enter the opening code. (Factory setting 1111)
▻ The blue LED lights up.
Press the "Bell" button.
▻ The blue and green LEDs light up.
You can now operate the receiver using the UP (5), STOP
(7) or DOWN (9) buttons.
The commands can only be given while the green
LED is lit.
Press the "Bell" button to disable the code button manu-
ally.
▻ The blue LED lights up and the green LED
goes out.
► Operation is complete.
The code button automatically disables the but-
tons after approx. 20 seconds.
