ENGLISH
3. Hardware Installation CHD3CU
3.1 Assembling the CHD3CU (When no hard disk is installed yet)
If you bought the CHD3CU with a hard disk pre-installed, you can skip this step and
continue to step 3.2
a. Remove the 2 screws at the back of the CHD3CU and remove the back plate.
b. Gently slide the hard disk tray out of the housing.
Note: You need to set your hard disk to 'Master' or 'Single', depending on the
type of hard disk you are using. How to make this setting is indicated on
your hard disk itself or in its manual.
c. Connect the power and IDE cable to the hard disk and place the hard disk in the
tray.
d. Use the notches on both sides of the tray to fasten the hard disk.
