9. Press the Transmitter Delete button on the siren in order to clear the siren's
register; the siren sounds an acknowledge tone.
10. On the control panel, perform the External Siren Test twice in order to register
the control panel's transmitter to the OS826's receiver.
To perform an External Siren Test:
• From the Service menu, select WL. Siren Test [7▼▼]; the siren
sounds an
Note: During the registration procedure, make certain that no other wireless
devices are transmitting so as not to interfere with registration. In the event that the
wrong transmitter is registered to the siren's receiver, you can delete the
transmitter by pressing the Transmitter Delete button while the Mode jumper is set
to Registration mode.
11. Set the control panel to Registration mode as follows:
• From the Programming menu, select Devices, Siren, Register [915
▲].
• Set the siren to Transmission mode by placing the Mode jumper (JP1)
as shown in Figure 4; the siren transmits a signal every few seconds.
• When Save? appears on the control panel's LCD display, press
the control panel's keypad.
12. Remove the Mode jumper on the siren and place it over one pin for storage
and disconnect the power supply.
13. Configure the Arming Tones jumper (JP2) as required. If the jumper is
removed, the siren sounds tones and flashes the strobe on arm/disarm. If the
jumper is installed, the siren flashes the strobe on arm/disarm but no tones
are sounded.
14. Choose a suitable mounting position for the siren. The siren should be
mounted on a flat surface in a highly visible position for maximum deterrence
against potential intruders.
15. Before permanently mounting the siren, test the reception from the exact
mounting position. If necessary, relocate the siren to a better position.
16. To mount the OS826, place the back cover in position against the wall and
mark the upper and lower mounting holes. Install wall anchors in the
appropriate positions.
17. Thread the cables through the cable entry hole on the back cover and mount
the back cover to the wall using four screws.
18. Connect the transformer to the terminal block and the backup battery to the
battery connector.– see Figure 2 for further information on wiring connections.
19. Replace the metal anti-vandal casing and the strobe cover.
20. Replace the front cover and secure using the cover screw provided. Make
certain that the screw is secured tightly so that it closes the front cover tamper
switch.
5
acknowledge tone when each transmission is received.
on
