ENGLISH
b. Press the following buttons at the same time and hold down while you turn on
the power:
The display shows "TRANSMIT" to indicate that the SM-1612 is ready to send.
2. Prepare to receive file dump: these actions have to be carried out on the
Scanmaster that has will receive the file dump.
a. Turn the power off.
b. Press the following buttons at the same time and hold down while you turn on
the power:
The display shows "RECEIVE" to indicate that the SM-1612 is ready to receive.
3. Start sending file dump:
On the Scanmaster showing "TRANSMIT" on its display, press the scene buttons 7
and 8 at the same time.
The display shows a small progression bar. Don't touch both Scanmasters during
this operation. At the end of the operation both units will automatically return to
normal.
Before you start using the unit that received the file dump, switch it off and on!

MAINTENANCE

The unit should be cleaned regularly using a wet cloth. We recommend internal
cleaning to be carried out by qualified personnel.

SPECIFICATIONS

Power Input:
AC/DC Power adapter:
DMX outputs:
Midi input:
Audio input:
Size:
Weight:
AND LOOK FOR OTHER PRODUCTS FROM JB SYSTEMS
JB SYSTEMS
• fixture2 button
• fixture3 button
• scene1 button
• Fixture8 button
• Fixture9 button
• Scene2 button
WWW.BEGLEC.COM
DC 9 ~ 12V 300mA minimum.
AC 240V, 50Hz
3pin XLR; DMX, channels 001
5pin Din
Cinch 0.1V ~ 1Vpp
48.3 x 13.4 x 8.5cm (19" / 3U)
2.7kg
SURF TO:
13/68 SCANMASTER 1612 (SM-1612)
OPERATION MANUAL
12Vdc / 300mA
192
