SN AXO Amp lif i e r Conn ect ion s
6. 3 SNAXO 362B MR co n n e cte d to 2 x N AP 2 50
mains input
and fuse
mains input
and fuse
Note:
The Naim Y-Link speaker cable splitter enables the twin
low frequency drivers of a Naim Ovator S-800 Ovator S-600 and
Ovator S-400 speaker to be driven from one amplifier channel.
Contact your local retailer or distributor for more information.
left
speaker BMR
left speaker LF1 &
LF2 via Naim Y-Link
speaker cable splitter
cable
direction
marker
(white)
right
speaker BMR
right speaker LF1 & LF2
via Naim Y-Link speaker
cable splitter
Interconnect Cables
4 pin DIN to XLR
7
