SN AXO Amp lif i e r Conn ect ion s
6 SN AXO Amplif ier Con nect io ns
6.1 S NAXO 24 2 conn e cte d to 2 x N AP 2 50
mains input
and fuse
mains input
and fuse
left
speaker HF
left
speaker LF
cable
direction
marker
(white)
Connection to two NAP 150 XS or NAP 200s follows the same
principle as shown below but with 4 pin DIN
to 4 pin DIN cables.
right
speaker HF
right
speaker LF
Interconnect Cables
4 pin DIN to XLR
5
