Icy Box IB-RD288M2 Handbuch Seite 6

Package contents
1x IB-RD288M2, 1x USB 3.1 Type-C™ data cable, 1x screw set, 1x manual
1. Key Features
• External RAID enclosure for 2x M.2 SATA SSDs
• Connector to PC: USB 3.1 Type-C™, up to 10 Gbit/s
• Supports RAID 0
• For 2x M.2 SATA SSDs with B-Key or B+M-Key, 22 x 30/42/60/80 mm
• High quality aluminum case
• Plug & Play, Hot Swap
• Supports Windows 7/8/10, MacOS 10.5 or later version
2. SSD Installation
1.
3.
3. Application
3.1 The external SSD can be connected to or disconnected from the computer via
USB cable without shutting down the computer.
3.2 Please await the end of read/write operations before disconnecting the SSD to
avoid data loss.
3.3 A new SSD must first be initialized, partitioned and formatted by the operation
system to be displayed by the system.
3.4 If the SSD isn't recognized instantly by the operating system please check:
- if the driver software is installed (USB),
- if the SSD is initialized, partitioned and formatted.
Manual: IB-RD288M2
2.
4.
