DESCRIPTION
The SA-Control remote control panel is designed for:
• SALDA ventilation units and other devices based on PRV (RIS EKO 3.0, RIRS EKO
3.0, Smarty 3R VER/VEL 3.0), MCB/MiniMCB (Smarty, AmberAir, AmberAir Compact)
controllers;
• Modbus-controlled devices.
Attention!
• Some of the articles in this guide may not apply to you. It depends on the type of the
control board on your device.
• Always choose accessories manufactured by Salda UAB. Otherwise, the warranty
will be void.
SA-CONTROL DIMENSIONS
In pic. 1 (page 56) the dimensions are shown: 123 x 82 x 15 (mm).
ACCESSORIES TO A SA-CONTROL
• 1x SA-Control control panel;
• 2x Cables (RJ45 for MCB/MiniMCB and RJ10 for PRV);
• 2x Fastening elements (screw 3,9 x 25 DIN 7981 – 2 pcs, nylon plug 5x25 – 2 pcs,
hammered steel plug 12x30 – 2 pcs);
• 1x Quick Launch Guide.

TECHNICAL DATA

Parameter
Mounting
Voltage
Communication line
Cable length
Dimensions (W x H x D)
Protection class
Ambient temperature
Relative humidity
2
Units Value
Surface
V (AC/DC) 24 (max 1,3 W)
ModBus RS485
[m] 13
[mm] 123 x 82 x 15
IP- 30
[°C] 10 - 40
[%] 10 - 80 (without condensation)
