Technical Data - hager S761-22 Montageanleitung

Technical data

Technical data
Programming LED
Programming key
Maximum total output power
Applications possible
Power supply
Operating temperature
Degree of protection
Insulation class
Power consumption
Installation
Dimensions (H x W x D)
Weight
230 V remote-controlled socket
1 red programming LED
1 programming push-button on the front panel of the remote-controlled socket
• 500 W/230 AC halogen lamp
• 1500 W/12 V extra low voltage halogen lamp
• 1500 W incandescent lamp
• 450 W low consumption bulb
• 400 W fluorescent tube
• ON/OFF
• timer
• presence simulation
• remote control
230 V - 50 Hz (16 A) disconnectable mains power supply with earthing protection
- 5°C min./+ 55°C max.
IP 30 and IK 04
Class 1
12 VA
Inside premises
98 x 54 x 77 mm
140 g
