Make sure that the saw blade does not
rest on or touch any objects when the
machine is switched on.
Switching on and off
Fig. A
• To switch on the machine, press the on/off
switch (3).
• To switch the machine to continuous mode,
keep the on/off switch (3) pressed and
simultaneously press the lock-on button (4).
• To switch off the machine, release the on/off
switch (3).
Sawing tips
• Adjust saw blade and stroke rate to suit the
material to be processed. For right radius
curves it is best to use a narrow saw blade.
Apply coolant or lubricant to deal with the
fluttering produced along the cut line when
sawing metal.
• Check wood, chip boards, building materials
etc, for foreign bodies (nails, screws etc.),
before sawing and remove them, if necessary.
• Clamp material well. Do not support the
workpiece with hand or foot. Do not touch
objects or the floor with the saw running
(danger of backlash).
• Put the footplate on the surface of the
workpiece, and saw through it with constant
contact pressure or feed. If the saw blade
seizes switch the machine off immediately.
Spread the gap with a suitable tool and pull
out the saw blade.
• After finishing work, switch off the machine
and only put down after it has come to a
complete standstill.
Plunge cutting
Fig. C
• Plunge cutting may only be used on soft
materials such as wood, aerated concrete,
gypsum plaster boards, etc.
• However, this requires a certain practise and
is only possible with short saw blades.
• Place the saw onto the workpiece and switch
it on.
• Ensure that the bottom edge of the footplate
rests on the workpiece surface as shown.
• Slowly saw into the workpiece at an angle,
moving the saw to a vertical position and
continue to saw along the cutting line.
• Switch the saw off and lift off the workpiece
when the work is complete.
Flush sawing
• Elastic bi-metal saw blades allow you to saw
protruding objects (e,g, water pipes, iron bars,
etc,) nearby the wall.
• Apply the saw blade directly to the wall and
bend slightly so that the footplate rests
against the wall.
• Switch the machine on and saw off the
workpiece keeping constant lateral pressure
against the wall.
5. SERVICE & MAINTENANCE
Make sure that the machine is not live
when carrying out maintenance work on
the motor.
The machines have been designed to operate
over a long period of time with a minimum of
maintenance. Continuous satisfactory operation
depends upon proper machine care and regular
cleaning.
Cleaning
Keep the ventilation slots of the machine clean
to prevent overheating of the engine. Regularly
clean the machine housing with a soft cloth,
preferably after each use. Keep the ventilation
slots free from dust and dirt. If the dirt does not
come off use a soft cloth moistened with soapy
water. Never use solvents such as petrol, alcohol,
ammonia water, etc. These solvents may damage
the plastic parts.
Lubrication
The machine requires no additional lubrication.
Faults
Should a fault occur, e.g. after wear of a part,
please contact the service address on the
warranty card. In the back of this manual you find
an exploded view showing the parts that can be
ordered.
Environment
To prevent damage during transport, the
appliance is delivered in a solid packaging which
consists largely of reusable material.
Therefore please make use of options for
recycling the packaging.
