6. Recognition of the Wireless Motion Detector by the
wireless alarm receiver.
Please, also refer to the manual for your alarm equipment when arranging for
the Wireless Motion Detector to be recognised by the system.
In this way, you are provided with an overview of the different alarm zones for
which the Wireless Motion Detector can be recognised.
To arrange for the Wireless Motion Detector to be recognised by the wireless alarm installation,
proceed as follows:
Step Action Function
1 Press the key
„PROG" on your
wireless alarm receiver.
2 Enter the You get into the
four-digit Programming mode.
mastercode.
3 Press You get into the
key 3 on the programming mode for
alarm receiver. acquiring new sensors.
4 Press key
1, 2, 3, 4, 5, 6, 7, 8, 9
or 0, according
to which memory posi-
you want to
use.
5 Activate A spoken message
the Wireless Motion confirms that the Motion
Detector. Detector was recognized
succesfully.
** Meaning of „Zone Status-LEDs" of step 3 in the table above:
„Zone Status LED" Explanation
Does not light up For this zone, no remote sensor was recognised yet.
Single blink For this zone, sensor 1 was recognised.
Double blink For this zone, sensor 2 was recognised.
Single blink and then double For this zone, sensor 1 and sensor 2 have been
blink recognised.

7. Battery replacement

• Loosen the screw of the battery cover on the rear.
• Remove the cover of the battery compartment.
• Remove the battery.
• Insert a new 9V PP3 battery.
• Slide the battery cover back in place.
• Tighten the screw of the battery cover.
8. Maintenance and Cleaning
The product requires no servicing, except for battery replacement.
Only have repairs performed by a specialist or specialist workshop.
Clean the product with a soft, clean, dry and lint-free cloth. If you wish to remove heavier dirt,
use a cloth, slightly moistened with lukewarm water.
Never use solvent-based cleansing agents, since these might damage the surface of the plastic
housing.
9. Disposal
a) General information
Please dispose of the device, when it is no longer of use, according to the current legal require-
ments.
b) Batteries and rechargeable batteries
As a consumer you are required (Battery Ordinance)to responsibly dispose of all used batteries and
rechargeable batteries;it is forbidden to throw them away with the normal household waste!
(Rechargeable) batteries and accumulators that contain pollutants are marked with
the symbols shown here, indicating that it is prohibited to dispose of them in
household waste. The designations for the heavy metals involved are: Cd =
cadmium, Hg = mercury, Pb = lead.
You can return your used batteries/rechargeable batteries free of charge to the offi-
cial collection points of your community, in our stores, or in any shop where batter-
ies or rechargeable batteries are sold.
You thus fulfil the legal requirements and make your contribution to protecting the environment!
10. System Range Information
Ranges and Disturbances
• The Wireless Motion Detector sensor works in the 433 MHz range which is also used by other
• The specified range of up to 100 m is the so-called free field range, i.e. the range within visible
Note
• The actual attainable distance between transmitter and receiver in normal operation is highly
3 short beeps of the
the alarm receiver confirms
11. Technical data
that you have entered the
Power supply : ......................................1 x 9V PP3 battery
correct code. 1 long beep
Detection angle ....................................100° horizontal
indicates erroneous code
Range: ..................................................up to 100m (free field)
entry.
Frequency:............................................433 MHz
As soon as you
Dimensions (WxHxD): ..........................65 x 87 x 47 mm
get into the programming
Weight: ................................................78 Grams
mode, the Zone Status LEDs
Operating temperature range: ..............-10°C to 50°C
on the alarm receiver light up
or blink.

12. Declaration of Conformity

** explained further in the fol-
lowing table.
Hereby we, Conrad Electronic, Klaus-Conrad-Straße 1, 92240 Hirschau (Germany), declare that
To select the cor-
this product complies with the essential requirements and relevant regulations of the guideline
rect memory position,
1999/5/EG.
please refer to the table
above.
The settings are saved
and you exit
the programming mode.
© Copyright 2009 by Conrad Electronic SE.
radio services. Operation and range may be a restricted due to devices that work on the same
or a neighbouring frequency.
contact between the transmitter and receiver. However in real-life operation, there are ceilings,
walls, garages or adjoining buildings between the transmitter and receiver, which affect and
reduce the range accordingly.
dependent of the installation site and environment. Normally, proper operation without prob-
lems with wireless reception should be possible in e.g. a detached house.
The declaration of conformity of this product can be found at www.conrad.com.
These operating instructions are a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240
Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or
the capture in electronic data processing systems require the prior written approval by the editor.
Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in
technology and equipment reserved.
