3. Layout, Connections & DIP-Switch

3.1 Layout

Front:
Power LED
Back:
© Copyright 2017 by EXSYS Vertriebs GmbH. All Rights Reserved
4x RJ45 Connector
1x USB 3.1 (Gen1)
Upstream C-Port
12
EX-1329
DIP-Switch
5V DC Connector for
optional Power Supply
