or spraying water, strong vibrations, or great mechanical strain.
• Do not put sources of naked flames such as candles on or next
to the device.
• Ensure sufficient ventilation of the power supply and the switch
during operation. Do not cover the units with newspapers, sheets,
curtains or similar.
Features:
- 2 HDMI inputs/8 HDMI output with HDMI Lock System
- fully support 1080p HDTV
- resolution: 480i, 480p, 720i, 720p, 1080i und 1080p
- HDMI 1.2a and HDMI 1.3 compatible
- HDCP compatible
- audio: Dolby Digital 7.1, DTS, True HD, DTS-HD, PCM
- intelligent recognition of active inputs
- built-in signal amplifier/equalizer for enable longer HDMI cable
- gold-plated contacts
- professional metal-housing design

Content of Package

- HC 428 Switch/Splitter
- 5V DC power adaptor
- Bracket set for wall mounting
- User's manual
Installation/Setup
You can place the switch on an even surface or mount it on or under a
surface by using the provided assembly brackets.
For fastening only use screws appropriate to the mounting surface.
Connection
Carefully read the input and output connection and/or compatibility
section in the relevant operating instructions of the devices that are
to be connected to the adapter.
Switch off the devices to be connected before connecting them to the
connecting jacks. Do not put them into operation again until you have
made all necessary connections and checked them over once again.
Stick to the same procedure when changing the connection to any of
the devices.
• Connect the inputs IN 1 to IN 2 with the outputs of your AV source
devices (DVD player, SAT receiver, etc.).
• Connect the exits OUT1 to OUT8 with the inputs of your display
monitors.
• Put the low-voltage plug of the enclosed power supply into the
DC 5V connector socket .
• Plug the power unit into a wall socket.
9
