RS-232 Connection for computer control application
Note:
To use the RS-232 connection for computer control
You can use the application software by double click
"HDMI Dual-Input Splitter.exe" that located in "HDMI Dual-Input
Splitter exe". If the computer shows the "MSCOMM32 is not
found", please install the application software from CD disc.
To install the software, please double click "setup.exe", and then
follow the installation instruction.
Before you connect the RS-232 cable, please make sure the power
of computer and HC 428 Splitter is off.
1. Connect the RS-232 cable form the COM Port (RS-232) of your
computer to the RS-232 port of HC 428 Splitter.
2. Turn on the power ofHC 428 Splitter, and computer.
3. Start the control software.
Operations of HC 428
Manual Operation
• Power On:
The power main switch is located at rear panel of the splitter.
Please switch it to turn on the power of splitter. The LED indication
light of power will be on.
• Power Off:
The power main switch is located at rear panel of the splitter.
Please switch it to turn off the power of splitter. The LED indication
light of power will be off.
• Selection:
Press the "SELECT IN" button once to select the inputs. The LED
will indicate which input is current source device.
