Getting the keyboard ready
1. Install the AA alkaline batteries (G) in the Wireless keyboard.
2. Remove the battery compartment cover (H) on the bottom of
the keyboard by squeezing the cover in from the tab (I) to
release it.
I
H
Selecting the Frequency Channel
The Wireless keyboard and Optical Mouse operates on two frequency
channels. To prevent interference when using two RF Optical Mice in
close proximity a different frequency channel should be used for each
mouse. Refer to the following to change the frequency channel for
your keyboard and mouse: Set the frequency channel on the receiver
(J) to 1 or 2. Set the frequency channel on the keyboard (K) and
G
mouse (L) to 1 or 2.
Inserting the Batteries to the
Receiver
Refer to the following to insert the
batteries:
1. Press the tab on the tab of the
receiver cover as shown here and
remove the cover.
2. Insert the two batteries. (The
correct polarity is indicated on
2
K
L
J
