6. Commissioning
Interval mode:
• Press the yellow button TIMER on the remote control.
• The device now emits fog time-controlled and the yellow indicator LED is lit.
• Set the desired interval time with the INTERVAL control.
• The device emits fog for the set time and then pauses for as long as the set time as well. Afterwards the described
interval starts again.
• To deactivate interval operation again, press the yellow button TIMER on the remote control again.
DMX mode:
• Each DMX device in a DMX chain requires an assigned DMX channel to be clearly identified by the controller.
• This DMX channel is defined by the DIP switches 1 to 9 on the back of the device. Each DIP switch is assigned
a value. The total of the assigned values define the assigned DMX channel.
DIP switch 10 does not have a function.
• Please refer to the table below for the values of the individual DIP switches 1 to 9. If a switch is in the position
"ON", it is activated, in position "OFF" it is deactivated.
DIP switch
1
2
3
4
5
6
7
8
9
Example:
The DIP switches 1, 3 and 5 are "ON", all other switches "OFF".
DMX channel = 1 + 4 + 16 = 21
24
DMX channel
1
2
4
8
16
32
64
128
256
