Check all cable connections and make sure there is a clear view (no obstacles) to the satellite and
the receiver is correctly adjusted. Then repeat this procedure.
☛ The menu item Upd Sat is not shown when the tracking function is deactivated (see sec-
tion 4.1).
Should the antenna lose the signal from the satellite (due to a passing boat, buildings on shore,
bridges, or superstructures on own boat), the display will interchange between Sat X (stored po-
sition of current satellite) and no Sig , for the duration of the missing satellite reception.
The tracking mode will automatically restart when the vessel is turned. The display interchanges
between scanning and Sat X. In case superstructures obstruct the view to the satellite, turn
the vessel or the satellite cannot be found!
☛ If you wish to select a specific satellite, refer to section 5.4.

4.1 Stop Tracking function in harbors

If the boat is in a harbor, the tracking function can be deactivated to stop the tracking (noise-reduc-
tion). Proceed as follows:
1. Press  repeatedly until the display flashes. This is the main menu.
2. To go to the setup menu, press  repeatedly until the display shows Setup (flashing), then
press  , Enter password, see section 3.4. If the password is correct you are in the Setup menu
with the display: Tracking .
3. Pressto select, and press  to toggle between ON and OFF. The tracking function must be
in OFF position to be deactivated. Confirm with
4. The display returns to Tracking . Press  repeatedly until the display shows quit . Con-
firm with  . The display returns to: Setup .
You are now back in the main menu and can switch to other satellites or make adjustments in the
setup menu.
☛ When the tracking function is deactivated, the antenna does not track the satellite, so it is pos-
sible that the TV picture sometimes can deteriorate or drop out. A realignment with the satel-
lite is always possible: Press  repeatedly until the display shows Sat X (flashing), then
press  .
18
English
.


5 Satellites

5.1 Adding new satellites

To search and store new satellites must be done in the harbor in calm waters! For every satellite
at least one program must be preprogrammed in the receiver to control the satellite position of the
antenna unit by means of the TV picture quality. Make sure the preprogrammed TV station for the
desired satellite is turned on at the receiver, as the system stops at each receivable satellite. The
satellite can be identified by the quality of the TV picture.
Please proceed as follows:
1. To go to the setup menu, press  repeatedly until the display shows Setup (flashing), then
press  . Enter password, see section 3.4. If the password is correct you are in the Setup menu
with the display: Tracking .
2. Press  repeatedly until New Sat appears. Press
☛ New Sat only appears in the display if free satellite storage positions are available. If all
storage positions are occupied, then the less required ones have to be deleted first. (See 5.3).
3. The legend ScnBand? will be shown for 2 seconds. After that, use the
band between Band 1 and Band 4 to select the band in which the satellite will be
searched:
Band 1 10700 MHz -11700 MHz (Polarization Vertical)
Band 2 10700 MHz -11700 MHz (Polarization Horizontal)
Band 3 11700 MHz -12750 MHz (Polarization Vertical)
Band 4 11700 MHz -12750 MHz (Polarization Horizontal)
Example:
Astra 1 Band 3
Hotbird Band 3
Astra 2 Band 3
Sirius Band 3
US Band 2
4. Confirm with  , or abandon with  .
5. The display interchanges between New Sat and Search? .
6. Confirm with  , or abandon with  .
7. If you chose 'abandon', the display will briefly show cancel and then return to the setup
 to select.
 key to change
