3. General Guidelines
Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.
Keep this device away from dust and extreme heat. Make sure the ventilation openings
are clear at all times. For sufficient air circulation, leave at least 1" (±2.5 cm) in front of
the openings.
Protect this device from shocks and abuse. Avoid brute force when operating the device.
•
Familiarise yourself with the functions of the device before actually using it. Do not allow operation
by unqualified people. Any damage that may occur will most probably be due to unprofessional use
of the device.
•
All modifications of the device are forbidden for safety reasons. Damage caused by user modifications
to the device is not covered by the warranty.
•
Mechanical wear is not covered by warranty.
•
Only use the device for its intended purpose. All other uses may lead to short circuits, burns,
electroshocks, lamp explosion, crash, etc. Using the device in an unauthorised way will void the
warranty.
•
Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and
the dealer will not accept responsibility for any ensuing defects or problems.
•
A qualified technician should install and service this device.
•
Do not switch the device on immediately after it has been exposed to changes in temperature.
Protect the device against damage by leaving it switched off until it has reached room temperature.
•
This device is designed for professional use on stage, in discos, theatres, etc. The VDPLW1601 can
be used indoor (<35°C, <75%RH) with an alternating current of max. 240V AC/50Hz.
•
Lighting effects are not designed for permanent operation: regular operation breaks will prolong their
lives. It is recommended to let the device cool down for ±15minutes after every two hours of
operation.
•
Use the original packaging if the device is to be transported.
•
Keep this manual for future reference.
4. Features
•
easy to control Red- Green laser
•
with circle, fan and line creating tunnel effects
•
DMX controlled via 5 channels
•
sound activation and auto control mode
•
high capacity and speed micro processor
•
low noise long lasting scanners
5. Overview
Refer to the illustrations on page 2 of this manual.
1
power LED
2
microphone
3
sensitivity knob
4
DIP switch
6. Installation
Refer to the illustrations on page 2 of this manual.
a) Overhead mounting
•
Have the device installed by a qualified person, respecting EN 60598-2-17 and all other applicable
norms.
•
The construction to which the device is attached should be able to support 10 times the weight of
the device for one hour without deformation.
•
The installation must always be secured with a secondary attachment e.g. a safety cable.
•
Never stand directly below the device when it is being mounted, removed or serviced. Have a
qualified technician check the device once a year and once before you bring it into service.
•
Install the device in a location with few passers-by and inaccessible to unauthorised persons.
•
Overhead mounting requires extensive experience: calculating workload limits, determining the
installation material to be used... Have the material and the device itself checked regularly. Do not
attempt to install the device yourself if you lack these qualifications as improper installation may
10.01.2011
VDP1401RGLD5
5
DMX512 input
6
DMX512 output
7
ON/OFF switch + safety key*
8
power input
4
* depends on model
©Velleman nv
