defects or problems
4. Features
•
wireless transmission of A/V signals through walls and between rooms
•
uses 5.8GHz frequency which gives less interference with other wireless
products than the 2.4GHz frequency
•
comes with: 2 x SCART to RCA A/V cable, IR extender cable and 2 power
adapters
•
optional video cables: AVB020/2.0, AVB020/5.0, AVW084, AVW084G, AVW085,
AVW085
5. Overview
Refer to the illustrations on pages 2 and 3 of this manual.
A 5.8 GHz antenna (folded upwards)
B channel selector switch
C ON/OFF switch
D infrared remote output (transmitter only)
E remote frequency selector (transmitter only) A=38KHZ; B=56KHz
F power connector (12VDC)
G S-video connector
H RCA video connector (yellow)
I RCA audio connector R (red)
J RCA audio connector L (white)
K power adaptor (2x)
L IR LED
6.

Installation

Refer to the illustrations on pages 2, 3, 4 and 5 of this manual. Make sure all
devices are disconnected from the mains before making any connections.
Transmitter [5]
•
The transmitter can be recognized easily as it has an IR output port [D] and
remote frequency selector [E] at the side.
•
Use the SCART-to-RCA A/V cable marked with TRANSMITTER (included) or
use an appropriate S-video cable (not included).
Note: when using an S-video cable, the RCA connectors are disabled. Always
use an S-video cable on both transmitter and receiver.
•
Connect the RCA video connector (yellow) to the video connector [H] and
connect the audio connectors (red, white) to the audio connectors [I] resp.
[J]. When using an S-video cable, simply connect it to the S-video connector
[G].
•
Connect the SCART connector to a SCART output connector or connect the free
end of the S-video cable to the S-video output port of the signal transmitting
device (e.g. satellite receiver, DVD, VCR ...., not incl.),
•
Connect the IR extender connector to the IR remote output port [D]. Place the
01.09.2010
AVMOD19
1 - side view
2 - rear view
3. - accessories
