ANSMANN ACCUfresh 5 plus Bedienungsanleitung Seite 3

Operating instructions
rechargeable batteries size Micro (AAA), Mignon (AA), BABY (C), MON-0 (D)
and a 9 Volt block NiCd/NiMH.
LED green on (1): Charging of cylindrical cells.
LED green flashes: Trickle charging of cylindrical cells.
LED red on (2): Charging of 9 Volt block.
LED yellow on (3):
Discharging of cylindrical cells.
Slide-switch (NiCd/NiMH) (4): Choose position NiCd or NiMH, according to
the cells inserted in the charger.
Discharge button (5) : Push this button to start the discharaina process of the
nickel/metal-hydride batteries. Do not insert other types of batteries. Danger of
By using rechargeable batteries and ANSMANN chargers you conserve the
environment and safe money by doing so. Rechargeable batteries are not to be
disposed in domestic waste. Give used batteries back to vour dealer or rather
to the battery collecting
p oint.
Keep 'your charger in a dry place (indoor use only). Danger of fire and electric
ower cables are to be taken to authorized dealers.
. .
place the batteries into the battery mounting adapter on the charaer. The
the charging box (shaped like a V). (Always insert batteries with correct
direction of poles according to the symbols in the charging box!). The charging
charger Accufresh 5 plus
nickel/cadmium and nickel/metal-hydride
time for NiCd cylindrical cells is approx. 8h and
16 h for NiMH cylindrical cells (if the slide switch
is adjusted to the right position). (Further details
cf. table of charging times ). After termination of
the charging process automatic switch over to
trickle charging is made. The cells can stay in the charger unrestrictedly, with
full capacity and without danger of overcharging. Before charging a defined
predischarge of the cylindrical cells can be started via the discharge button
(PRESS). Thus the feared memory effect (capacity loss) is avoided. After
discharge, the fast charging process starts automatically. Depending on the
condition of the battery, the discharging process can take several hours. After
termination of the charging process automatic switch over to trickle charging is
made.
(Always insert batteries with correct direction of poles according to the symbols
in the charging box!) The 9 Volt block is charged with a constant charging
current. Pay attention to the charging time (cf. table of charging times). After
charge, the 9 V block has to be taken out. (Danger of overcharging!). A
in. In order to guarantee a perfect function of the charger keep the contacts
inside the charging boxes free of dirt. Do not plug in the charger in case of
damaged cabinet or power cable. Never open the charger. Chargers in need of
230V - 50Hz
Sec.: 4 x 1.45v=
1 x lOV=
4 x 600mA / 300mA / l30mA / 50mA
1 x 12mA
Error and misprint excepted
